MATCH UP 1FX Class D Subwoofer Amplifier 1000W
£259.00
Sale price
£259.00
Regular price
Skip to product information
This compact Class D amplifier delivers up to 1000 Watts of power, making it a brilliant upgrade for factory subwoofer setups. It features an integrated active crossover and a high-level input with ADEP.3 technology, ensuring seamless integration with modern car audio systems. The DirectDSP function lets you bypass the crossover for a pure, unfiltered signal path. With Start-Stop capability and a compact footprint, it fits neatly into tight spaces while driving even high-performance subwoofers with ease.
Amplifier Technology: Class D
Number of Channels: 1
RMS Power @ 4 Ohms: 350 W
RMS Power @ 2 Ohms: 600 W
RMS Power @ 1 Ohm: 900 W
Max Output Power: 1000 W RMS @ 1 Ohm
Frequency Response: 10 Hz - 25,000 Hz
Signal-to-Noise Ratio: 108 dB (A-weighted)
Total Harmonic Distortion (THD): 0.002%
Damping Factor: 160
Lowpass Filter: 50 Hz - 250 Hz (adjustable, defeatable)
Subsonic Filter: 15 Hz (defeatable)
Slope: 12 dB/octave
Input Sensitivity (RCA): 0.5 - 3 V or 1 - 6 V
Input Sensitivity (High-Level): 2.5 - 16 V or 5 - 32 V
Inputs: 1 x RCA/Cinch, 2 x High-Level Speaker Input, 1 x Remote In, 1 x Remote Control Input
Outputs: 1 x Speaker Output
Operating Voltage: 10.5 - 18 V (min. 6 V for 5 sec.)
Idle Current: 1050 mA
Fuse Rating: 2 x 30 A LP-Mini (APS)
Dimensions (H x W x D): 46 x 130 x 153 mm
Additional Features: Active crossover, Start-Stop capability, ADEP.3, DirectDSP function, Clipping LED
