MATCH M 5.4DSP 5-Channel Micro Amplifier with 9-Channel DSP
£599.00
Sale price
£599.00
Regular price
Skip to product information
This 5-channel micro amplifier packs a serious punch, delivering up to 800 watts of peak power while staying compact enough to fit in tight spaces. Its built-in 64-bit audio signal processor offers nine DSP channels for flexible system configuration, including virtual channel processing and proprietary sound enhancements like RealCenter and Augmented Bass Processing. Two power modes let you choose between maximum performance and efficient plug-and-play operation without a separate power supply. The smart control port simplifies connections for optional remote controls, and the Class GD technology ensures high efficiency across the board.
Amplifier Technology: Class GD
Number of Channels: 5
RMS Power @ 4 Ohm (HighPower Mode): 4 x 60 W
RMS Power @ 4 Ohm (MidPower Mode): 4 x 35 W
Subwoofer Output @ 4 Ohm: 1 x 90 W
Subwoofer Output @ 2 Ohm: 1 x 160 W
DSP Resolution: 64 Bit
DSP Processing Power: 295 MHz
Sampling Rate: 48 kHz
Frequency Response: 20 Hz - 20,000 Hz
Signal-to-Noise Ratio (Digital Input): > 105 dB
Signal-to-Noise Ratio (Analogue Input): > 99 dB
THD (Total Harmonic Distortion): < 0.03%
Inputs: 4 x High-Level Speaker Input, 1 x Optical SPDIF (12-96 kHz), 1 x Remote In
Outputs: 5 x Speaker Output, 4 x RCA Line Output, 1 x Remote Out
Input Sensitivity: 5 - 11 V
Operating Voltage: 10.5 V (6 V for up to 5 seconds)
Current Draw (Max): 40 A
Idle Current Draw: 280 mA
Damping Factor: > 50
Operating Temperature Range: -40 °C to +70 °C
Fuse: 1 x 30 A Maxi Blade Fuse (FK3)
Dimensions (H x W x D): 35 x 85 x 110 mm
Weight: 0.9 kg
