Helix P ONE MK2
Raw power – Total control
Loads of power and tremendous stability: Our new P ONE MK2 is the ideal performance package for any subwoofer configuration. With up to 1,800 Watts RMS @ 1 Ohm, the upgrade to our powerful mono amplifier is going to rev up any woofer while always maintaining full control due to its enormous damping factor.
High-Res Audio and a fully digital signal chain
1-channel High-Res amplifier with 1 Ohm stability and digital signal input
The P ONE MK2 is designed for more than just driving subwoofers. With its particularly wide frequency range up to 40 kHz and excellent signal-to-noise ratio as well as the extremely low THD, you can expect nothing less than High-Res sound quality, making it well suited for the use as a fullrange amplifier.
Due to the newly integrated optical digital input, an interference-free and ground-isolated signal transmission in the best possible quality all the way into the amplifier is now possible. The input receives signals up to a 96 kHz sampling rate lossless via light conductor and converts them back to the analog level via a cutting-edge 32-Bit BurrBrown D/A converter. Thus, the P ONE MK2 can be perfectly combined with one of our DSP amplifiers with optical digital output, for example the HELIX P SIX DSP ULTIMATE
| Power RMS ≤ 1% THD+N | |
| - @ 4 Ohms | 1 x 500 Watts |
| - @ 2 Ohms | 1 x 880 Watts |
| - @ 1 Ohm | 1 x 1,500 Watts |
| - bridged @ 4 Ohms | - |
| - bridged @ 2 Ohms | - |
| Max. output power per channel* | Up to 1.800 Watts RMS @ 1 Ohms |
| Amplifier technology | Class D |
| Inputs | 2 x RCA / Cinch 1 x Remote In 1 x Optical SPDIF (28 - 96 kHz) |
| Input sensitivity | RCA / Cinch 0.5 - 8 Volts |
| Input impedance RCA / Cinch | 20 kOhms |
| Input impedance highlevel | - |
| Outputs | 1 x Speaker output |
| Output voltage RCA / Cinch | - |
| Signal converter for digital input | BurrBrown 32 Bit DA converter |
| Frequency response | 21 Hz - 40,000 Hz |
