Power. Precision. Control: MATCH UP 1FX
Exceptionally compact and powerful, this highly efficient high-fidelity Class D amplifier delivers exceptional sound quality in combination with an impressive output power of up to 1000 Watts. The immense power drives even high-performance subwoofers to peak performance and makes the UP 1FX the perfect companion for all HELIX and MATCH subwoofer chassis and enclosure subs.
Perfect integration without compromises
Simple and uncompromising – the MATCH UP 1FX offers the ideal solution for upgrading factory subwoofer amplifiers, thanks to the integrated active crossover and high power stereo highlevel input with ADEP.3, max. 32 V input voltage, and signal summing. The mono RCA / Cinch input as well as the DirectDSP function make it the perfect complement to our MATCH UPGRADE DSP amplifiers. Furthermore, the power supply with Start-Stop capability and extended input voltage range of up to 18 V enables the amplifier to be used in modern electric vehicles
Technical data
| Power RMS | |
| - @ 4 Ohms | 1 x 350 Watts |
| - @ 2 Ohms | 1 x 600 Watts |
| - @ 1 Ohm | 1 x 900 Watts* |
| - bridged @ 4 Ohms | - |
| - bridged @ 2 Ohms | - |
| Max. output power | Up to 1000 Watts RMS @ 1 Ohm |
| Amplifier technology | Class D |
| Inputs | 1 x RCA / Cinch 2 x Highlevel speaker input 1 x Remote In 1 x Remote control input |
| Input sensitivity | RCA / Cinch 0.5 - 3 Volts or 1 - 6 Volts Highlevel 2.5 - 16 Volts or 5 - 32 Volts |
| Input impedance RCA / Cinch | 8.6 kOhms |
| Input impedance highlevel | 9 - 33 Ohms |
| Outputs | 1 x Speaker output |
| Output voltage RCA / Cinch | - |
| Signal converter for digital input | - |
| Frequency response | 10 Hz - 25,000 Hz |
