HELIX K 10S 250mm Dual Voice Coil Subwoofer 84.5mm Depth
£174.00
Sale price
£174.00
Regular price
Skip to product information
The HELIX K 10S is a shallow 250mm subwoofer designed for compact enclosures, delivering powerful bass without compromise. Its ultra-stiff sandwich paper cone and high-excursion rubber surround handle amplifier power effortlessly, converting it into deep, precise low-end. The dual 2-ohm voice coil offers flexible wiring configurations to match your amplifier, while the rear-threaded magnet system allows bolting to the enclosure back wall to reduce cabinet resonance. This DIY-friendly package includes a protective grille, trim ring, and gold-plated terminal for a complete installation solution.
Type: Single chassis subwoofer
Diameter: 250 mm
Outer Diameter: 262 mm
Mounting Diameter: 229 mm
Mounting Depth: 84.5 mm
Impedance: 2 x 2 Ohm
DC Resistance: 2 x 1.6 Ohm
RMS Power: 300 W
Max Power: 600 W
Resonance Frequency: 34 Hz
Mechanical Q Factor: 6.37
Electrical Q Factor: 0.49
Total Q Factor: 0.45
Compliance: 198 μm/N
Equivalent Volume: 34 L
Force Factor: 12.7 Tm
Efficiency 1W/1m: 87.0 dB
Cone Area: 353 cm²
Moving Mass: 112 g
Cone Material: Sandwich paper
Mechanical Resistance: 3.73 kg/s
Voice Coil Diameter: 50.8 mm
Voice Coil Winding Width: 19 mm
Max Linear Excursion: +/- 6.0 mm
Surround Material: Long-throw rubber
Recommended Sealed Box Volume: 14 L
Sealed Box -3dB Frequency: 46 Hz
Recommended Bass Reflex Volume: 16 L
Bass Reflex Port Diameter: 70 mm
Bass Reflex Port Length: 38 cm
Bass Reflex Tuning Frequency: 37 Hz
Bass Reflex -3dB Frequency: 39 Hz
