HELIX IK S10 Shallow Subwoofer DVC2 10 Inch 250mm
SVC2 – 1 x 2 Ohms
£174.00
Sale price
£174.00
Regular price
Skip to product information
The HELIX IK S10 delivers deep, powerful bass from a remarkably shallow chassis, perfect for compact and flat enclosures. Its stiff sandwich paper cone and heavy-duty drive system convert amplifier power into impressive sound pressure without compression. The magnet system features a threaded hole on the back, allowing the woofer to be screwed directly to the enclosure's back panel to reduce vibrations. Available in a 2 x 2 Ohm dual voice coil configuration, it offers flexible wiring options for various amplifier setups. This DIY-friendly subwoofer comes complete with a protective grille, gasket, and gold-plated connection terminal.
Type: Subwoofer
Diameter: 250 mm / 10 inch
Impedance: 2 x 2 Ohm
Power Handling RMS / Max: 300 / 600 Watts
Resonance Frequency (Fs): 34 Hz
Sensitivity: 90.0 dB @ 2.83V / 1m
Cone Material: Sandwich paper cone
Voice Coil Diameter: 50.8 mm
Max. Linear Excursion (Xmax): +/- 6.0 mm
Outer Diameter: 262 mm
Installation Diameter: 229 mm
Installation Depth: 84.5 mm
Weight: 4.6 kg
HELIX IK S10 Shallow Subwoofer DVC2 10 Inch 250mm
£174.00
Sale price
£174.00
Regular price
Type: Subwoofer
Diameter: 250 mm / 10 inch
Impedance: 2 x 2 Ohm
Power Handling RMS / Max: 300 / 600 Watts
Resonance Frequency (Fs): 34 Hz
Sensitivity: 90.0 dB @ 2.83V / 1m
Cone Material: Sandwich paper cone
Voice Coil Diameter: 50.8 mm
Max. Linear Excursion (Xmax): +/- 6.0 mm
Outer Diameter: 262 mm
Installation Diameter: 229 mm
Installation Depth: 84.5 mm
Weight: 4.6 kg
